ET85704V
Contact
General Description
ET85704 offers low voltage operation, negative-rail input, rail-to-rail output, as well as excellent speed/power consumption ratio, providing an excellent bandwidth (250 MHz) and slew rate of 180 V/us. ET85704 is unity gain stable and feature an ultra-low input bias current.
Specification
Sample
Features
- High Gain Bandwidth:250 MHz
- Rail-to-rail Output
- 1.5 mV Typical Vos
- Input Voltage Range: -0.2 V to 3.9 V with VS = 5 V
- Supply Range:2.5 V to 5.5 V
Technical Documentation
| Type | Title | Format | Date |
|---|---|---|---|
| Datasheet | ET85704V Datasheet | 2025-11-12 |
