General Description
ES1805P4N3 is integrated 18VRWM and 5VRWM DFN2020-3L package Transient Voltage Suppressor
Specification
Sample
Features
- Bidirectional asymmetry TVS
- 200A Peak Pulse Current@5VRWM(tp = 8/20μs）
- 150A Peak Pulse Current@18VRWM(tp = 8/20μs）
- Excellent Clamping Capability
- DFN2020-3L package
Technical Documentation
| Type | Title | Format | Date |
|---|---|---|---|
| Datasheet | ES1805P4N3 Datasheet | 2025-11-07 |
