General Description
The ET633XX series of CMOS low dropout regulators are designed specifically for portable battery-powered applications which require ultra-low quiescent current. The ultra-low consumption of type 0.6uA ensures long battery life and dynamic transient boost feature improves device transient response for wireless communication applications.
The device is available in small DFN4(1mm ×1mm) or SOT23-5 packages.
Specification
Sample
Features
- Operating Input Voltage Range From 2.2V to 5.5V
- Fixed Output Voltage Range:1.1V~3.6V(1.1V/1.2V/1.5V/1.8V/1.9V/2.1V/2.5V/2.8V/3.0V/3.3V and etc)
- Ultra-Low Quiescent Current Typical 0.6uA
- Low Dropout is Typical 450mV at 300mA@VOUT=1.8V
- High Output Voltage Accuracy ±2%
- Stable with Ceramic Capacitors 1uF
- Over-Current Protection
- Thermal Shutdown Protection
- Available in Small DFN4 (1mm ×1mm) Packages
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
- Offered DFN4 and SOT23-5 Packages
